2025 0419 Raspberry Pi and device tree

I have just finished adding support for psyopsOS to the Raspberry Pi. Along the way I learned a few things about how device trees and the Pi that surprised me.

U-Boot needs its own device tree

The Pi’s firmware has a pretty nice Linux loader, but a feature of psyopsOS is A/B updates, and to support selection between two different runtime operating systems, I needed to use U-Boot¹.

U-Boot needs its own device tree. Device trees come from the Linux kernel, so U-Boot is tied to the Linux kernel source. Typically, a U-Boot binary for Raspberry Pi will set a default dtb file at compilation time, maybe bcm2711-rpi-4-b.dtb for the Raspberry Pi 4B. When booting U-Boot on the Raspberry Pi, the device_tree=... configuration setting in the Pi’s config.txt will override whatever U-Boot has set as its default.

The U-Boot device tree can be different from the kernel device tree

When booting a kernel, you can specify a different device tree than the one used in U-Boot. Which is good for psyopsOS, because the whole point of the psyopsOS A/B system is to enable upgrading the non-booted A/B side, including the kernel, without changing the bootloader.

U-Boot needs a device tree like the one it was compiled with, NOT necessarily like the one used in the kernel that it’s booting.

VideoCore needs device tree overlays (sometimes)

VideoCore is the proprietary Broadcom GPU firmware. On the Pi, it is loaded first, before any bootloaders like U-Boot, and before the Linux kernel. (VideoCore can also load a Linux kernel directly, which is the usual way to boot a Pi.) The config.txt file on a Raspberry Pi boot partition configures VideoCore.

The device tree system has base device trees for a single device, like bcm2711-rpi-4-b.dtb for the Raspberry Pi 4B, and optional overlays that can be applied on top of those bases.

For psyopsOS, I want to have a console listening on the serial port so that I can do emergency maintenance on any machine with a laptop and a serial adapter without a full monitor and keyboard. I’m using the primary PL011 UART (which Linux sees as /dev/ttyAMA0), which is used by the Bluetooth subsystem by default. I have to use an overlay to disable bluetooth to access this UART. There is a device tree overlay file called disable-bt.dtbo that does this.

When booting a Pi the normal way, where VideoCore loads Linux directly based on config.txt, you need to have /overlays/disable-bt.dtbo on the boot filesystem, and set this in config.txt:

overlay=disable-bt

When I had VideoCore load U-Boot, I took this out, because I applied the overlay inside U-Boot. But my kernel could never see the serial port.

It turns out that the disable-bt overlay is needed both by the kernel and by VideoCore. When it is set in config.txt, VideoCore reconfigures the hardware to give the GPIO pins to the UART, rather than to Bluetooth. (I think this is called “pin muxing”, but I don’t understand it very well.)

Example with separate dtb(o) files for U-Boot and Linux

So in my boot partition, I have:

• u-boot.bin, the U-Boot binary
• u-boot.dtb, the Raspberry Pi 4B device tree base file that U-Boot was built with.
• overlays/disable-bt.dtbo, the device tree overlay that disables Bluetooth and changes the pin muxes so that GPIO 14/15² are serial TX/RX. This was built from the same kernel sources that built u-boot.dtb. Note that this path is special. The device tree base file can be set with device_tree=... in config.txt, but the overlay=... lines do not take a path, they take a name like disable-bt, which VideoCore takes to mean /overlays/disable-bt.dtbo.
• A config.txt file that references these:

  device_tree=u-boot.dtb
  dtoverlay=disable-bt
  kernel=u-boot.bin
  enable_uart=1
  uart_2ndstage=1


And in each psyopsOS A/B side, I have:

• kernel, a Linux kernel that U-Boot can load (from the Alpine linux-rpi package, although it could be hand built instead)
• initramfs, an initramfs that was built alongside the kernel
• /dtbs/bcm2711-rpi-4-b.dtb, a device tree base file for the Raspberry Pi 4B that was built with the kernel.
• /dtbs/overlays/disable-bt.dtbo, a device tree overlay file that disables bluetooth and was built alongside the kernel. This path is not special, because I load an absolute path to the dtbo in the U-Boot script.
• … other files not relevant here

The A/B kernel, dtb, and dtbo might be the same version as the ones on the boot partition, but they don’t have to be. Over time, as I upgrade the A and B sides, those versions will change. The boot volume will change much less often, if at all.
